How do you measure the performance of a solid-state battery?

Measuring solid-state battery performance requires a combination of electrochemical, mechanical, and structural characterisation methods. Because solid-state batteries replace the liquid electrolyte with a solid ionic conductor, conventional liquid-cell testing protocols must be adapted or extended to capture the unique behaviour of solid interfaces, stack pressure, and ion transport. The sections below address the most important questions researchers encounter when designing a solid-state battery testing programme.

What makes solid-state batteries so difficult to test?

Solid-state batteries are difficult to test because their performance is governed by solid-solid interfaces that are highly sensitive to contact quality, stack pressure, and processing history. Unlike liquid electrolyte cells, where the electrolyte conforms to electrode surfaces, solid electrolytes create rigid interfaces that can develop voids, delamination, or cracking under cycling-induced volume changes.

Several factors compound the challenge:

Interface contact resistance: Poor physical contact between the electrode and solid electrolyte layer creates high interfacial impedance that is not present in liquid systems.
Pressure sensitivity: Ionic conductivity and capacity retention in many solid electrolytes depend on the applied stack pressure, which must be controlled and monitored throughout the test.
Material diversity: Oxide, sulfide, and polymer solid electrolytes each behave differently under thermal cycling, humidity, and mechanical stress, requiring tailored test conditions.
Fabrication variability: Small differences in pellet density, sintering conditions, or electrode coating thickness can produce large performance differences between nominally identical cells.

These factors mean that reproducing results between laboratories, or even between consecutive builds in the same lab, requires strict control of cell assembly conditions and test parameters. Solid-state battery characterisation therefore demands more from the test cell hardware than standard liquid-electrolyte research.

What electrochemical methods are used to measure solid-state battery performance?

Solid-state battery performance is measured using galvanostatic cycling, rate capability testing, electrochemical impedance spectroscopy (EIS), and cyclic voltammetry (CV). These methods, applied individually or in combination, quantify capacity, coulombic efficiency, rate capability, and resistance contributions from the different layers within the cell.

Galvanostatic cycling and rate capability

Galvanostatic cycling at a defined C-rate is the primary method for tracking specific capacity (mAh/g or mAh/cm²) and coulombic efficiency over repeated charge-discharge cycles. Rate capability tests, in which the C-rate is stepped from low to high and back, reveal how well the solid electrolyte supports ion transport under demanding conditions. A significant drop in specific capacity at higher C-rates typically indicates transport limitations within the solid electrolyte or at the electrode-electrolyte interface.

Cyclic voltammetry

CV is used to identify oxidation and reduction events within the operating voltage window, assess the electrochemical stability of the solid electrolyte, and detect unwanted side reactions at electrode surfaces. In solid-state cells, the scan rate must often be reduced compared to liquid-electrolyte cells to allow sufficient time for ion transport across the solid interface.

How does EIS characterise the interfaces inside a solid-state battery?

Electrochemical impedance spectroscopy (EIS) characterises solid-state battery interfaces by resolving the resistive and capacitive contributions of each layer in the cell stack as a function of frequency. By fitting the resulting Nyquist plot to an equivalent circuit model, researchers can separately quantify bulk electrolyte resistance, grain boundary resistance, and interfacial charge-transfer resistance.

In a typical solid-state cell EIS spectrum, three distinct features are observed:

High-frequency intercept: Represents the bulk ionic resistance of the solid electrolyte. This value is directly related to ionic conductivity and can be used to calculate conductivity in S/cm when the geometry of the electrolyte layer is known.
Mid-frequency semicircle: Corresponds to grain boundary resistance in polycrystalline electrolytes, or to the resistance of an interfacial layer such as a lithium-ion conducting interphase that forms at the anode surface.
Low-frequency semicircle or tail: Reflects charge-transfer resistance at the electrode-electrolyte interface and, in some configurations, solid-state diffusion within the electrode.

Tracking how these impedance components evolve with cycle number, temperature, or applied pressure provides mechanistic insight into degradation pathways. An increase in the mid-frequency semicircle over cycling, for example, indicates growth of an interfacial layer, analogous in some respects to the Solid Electrolyte Interphase (SEI) that forms on anodes in liquid-electrolyte cells, but with different kinetics and composition in solid-state systems.

Why do mechanical measurements matter for solid-state battery testing?

Mechanical measurements matter for solid-state battery testing because electrode volume changes during cycling directly affect interfacial contact, stack pressure, and long-term cell integrity. In solid-state cells, the solid electrolyte cannot accommodate these changes by flowing or redistributing as a liquid would, so thickness changes translate into mechanical stress that can fracture the electrolyte or delaminate the interface.

Dilatometry, the precise measurement of thickness change as a function of state of charge, quantifies the expansion and contraction of the electrode stack. These data are essential for:

Selecting electrode materials and loadings that remain mechanically compatible with the solid electrolyte over hundreds of cycles
Designing cell hardware that maintains adequate stack pressure without over-constraining the cell
Correlating mechanical events, such as sudden thickness discontinuities, with electrochemical anomalies in the capacity or voltage profile
Validating computational models of electrode mechanics

For lithium metal anodes in particular, the large volumetric change associated with lithium plating and stripping makes dilatometric monitoring a critical part of the characterisation workflow. The ECD-4-nano offers high-resolution dilatometry with sub-nanometre resolution, enabling researchers to detect even small irreversible thickness changes that signal the onset of void formation or electrolyte fracture.

What test cell design is needed for solid-state battery measurements?

Solid-state battery measurements require a test cell that applies and maintains a defined, uniform stack pressure throughout the experiment, accommodates rigid pellet or thin-film electrolyte geometries, and provides electrical connections suitable for four-wire EIS measurements. Standard spring-loaded coin cells are generally inadequate because they cannot control or measure the applied force precisely.

Key design requirements include:

Controlled uniaxial pressure: A screw-applied or pneumatic force mechanism with a defined contact area allows pressure to be expressed in MPa and adjusted reproducibly between experiments.
Rigid current collectors: Hard, flat current collectors ensure uniform current distribution across the electrolyte pellet and prevent local hot spots that would distort impedance measurements.
Hermetic sealing: Sulfide-based solid electrolytes are highly sensitive to moisture and must be assembled and tested under an inert atmosphere. The cell design must prevent ingress of air or water vapour.
Temperature control compatibility: Many solid electrolytes are characterised over a range of temperatures to extract activation energies for ionic conduction. The cell must be compatible with a temperature-controlled environment.
Force measurement integration: For the most rigorous work, the cell should incorporate a load sensor so that the actual force experienced by the stack is recorded alongside the electrochemical data.

Conventional test cells present several practical limitations that make meeting these requirements difficult. Assembly failure rates are high — studies cite a 43% failure rate, meaning even experienced builders typically achieve only 4 out of 5 working cells, while inexperienced ones fall below 50%. Conventional cells also do not include a force sensor: only the initial pressure is set, and mechanical settling can reduce it over time without any indication. Electrode material is often compressed inhomogeneously, and the O-ring seals and PEEK housings commonly used absorb significant moisture, requiring drying at 120°C under vacuum and increasing the risk of contamination.

The PAT-Cell-Solid and PAT-Cell-Force from EL-CELL address these limitations directly. Both cells use the PAT-Solid-Core insert, which features guided plane-parallel tungsten carbide plungers and a dedicated pressing tool to ensure homogeneous compression of the electrode material. Tungsten carbide withstands high mechanical loads without embedding particles into the plunger surface — a known problem with softer materials that gradually alters cell geometry and requires grinding or polishing between measurements. Instead of O-rings, EL-CELL cells use aluminum seals and glass-metal feedthroughs, and replace PEEK with PPS plastic, which absorbs significantly less moisture and reduces both contamination risk and preparation time. The standardised assembly procedure means that nearly every cell runs without failure. The PAT-Cell-Force additionally incorporates an integrated force sensor for continuous monitoring of stack force during cycling; an optional gas pressure sensor can be added to distinguish force changes caused by gas evolution from purely mechanical ones.

What are the key performance indicators for a solid-state battery?

The key performance indicators (KPIs) for a solid-state battery are specific capacity, coulombic efficiency, capacity retention over cycling, ionic conductivity of the electrolyte, interfacial resistance, and rate capability. Together, these metrics describe how well the cell stores and delivers energy and how that performance evolves with use.

Specific capacity (mAh/g or mAh/cm²): The amount of charge stored per unit mass or area of active material. This is the primary metric for evaluating electrode materials and should always specify whether it is normalised to the cathode, anode, or total electrode mass.
Coulombic efficiency: The ratio of discharge capacity to charge capacity in each cycle, expressed as a percentage. Low coulombic efficiency in early cycles indicates irreversible side reactions at the electrode-electrolyte interface.
Capacity retention: The fraction of initial capacity retained after a defined number of cycles. Rapid capacity fade in solid-state cells often points to interfacial degradation or electrolyte fracture rather than active material loss.
Ionic conductivity (S/cm): Determined from EIS, this reflects the intrinsic transport capability of the solid electrolyte and is strongly temperature-dependent.
Interfacial resistance (Ohm·cm²): The charge-transfer resistance at the electrode-electrolyte interface, extracted from EIS. This is often the dominant source of overpotential in solid-state cells and increases with cycle number as interfacial layers grow.
Rate capability: The ability to maintain specific capacity at increasing C-rates. A steep capacity-rate curve indicates that ion transport, rather than thermodynamic capacity, is the limiting factor.
Overpotential: The difference between the thermodynamic electrode potential and the actual potential under current. High overpotentials in solid-state cells signal resistive losses at the interface or within the electrolyte bulk.

Monitoring these KPIs in parallel, rather than in isolation, gives the most complete picture of solid-state battery performance and makes it easier to identify which component or process is limiting the cell.

How EL-Cell GmbH supports solid-state battery research

EL-Cell GmbH provides test equipment designed to address the specific demands of solid-state battery characterisation, from controlled-pressure cell hardware to high-resolution dilatometry and multi-channel electrochemical testing.

Our product range relevant to solid-state battery testing includes:

PAT-Cell-Solid: A test cell designed for solid electrolyte pellets, with controlled uniaxial stack pressure, EIS-compatible four-wire connections, and compatibility with inert-atmosphere assembly.
PAT-Cell-Force: A test cell with an integrated load sensor for continuous force monitoring during cycling, enabling direct correlation between mechanical and electrochemical data.
ECD-4-nano: A high-resolution electrochemical dilatometer with better than 5 nm thickness resolution, suitable for quantifying electrode expansion in solid-state configurations.
PAT-Tester-i-16: A 16-channel potentiostat/galvanostat with full EIS capability and integrated temperature-controlled cell chamber, supporting the complete electrochemical characterisation workflow for solid-state battery research.

All instruments are designed to work together as an interoperable system, reducing integration effort and ensuring that mechanical, thermal, and electrochemical data are collected under consistent, well-defined conditions. If you are setting up a solid-state battery research workflow and would like to discuss which configuration best suits your electrolyte system and experimental requirements, contact our Application Laboratory team directly to speak with our application specialists.
